Cold storage panels for coolers, freezers and cold rooms.
Insulated metal panels for the walls and ceilings of coolers, freezers and cold rooms: Kingspan QuadCore, 2 to 8 in. thick and foamed in place. A room held down to -20°F takes R-32 at minimum.
Installed by our crews, or supplied material-only to the contractor on the job.
The room size, the temperature it holds, and the drawings if there are any. Monday – Friday, 8:00 AM – 4:30 PM.
Choosing the thickness is choosing the R-value.
Standard insulated panels run from 2 to 8 inches thick. Insulating value is roughly R-8 per inch, so choosing the thickness is choosing the R-value.
Most cooler and freezer panels we use now are foamed in place, not laminated. The foam is injected between two steel skins with tongue-and-groove edges. Compared with a laminated panel, there is very little chance of delamination, and the fire rating is better.
Minimum run is 1,000 square feet per color. A modified-polyester white and a plain polyester white are visibly different whites, and panels from two different runs can stand out beside each other, on a ceiling most of all. Order a room's panels together.
What goes into a cold room.
Cooler or freezer down to -20°F
R-32 minimum, about 4" at R-8 per inch.
The panel: QuadCore KS Shadowline Interior
Kingspan's interior room panel, with a double tongue-and-groove joint, for the walls and ceilings of coolers, freezers and food plants. Kingspan's current figures are on kingspanpanels.us.
QuadCore KS Shadowline InteriorSkins
G90 galvanized, white modified polyester, Plastisol (PVC-coated steel), 304 2B stainless, embossed and 304 2B stainless, shadow line.
A face for wash-down
CLEANsafe 120 is a PVC film laminated to the metal, ordered on the panel face where wash-down chemicals and humidity would take an ordinary paint finish apart.
CLEANsafe 120Trim
When we supply the panels, the formed metal trims come with them, with the installation drawings and fastening details.
Doors
Jamison cooler and freezer doors, sized to the opening in the panel wall. They are special order: lead time runs five to six weeks, and they are not returnable.
Jamison cooler and freezer doorsThe floor
A freezer room needs insulation under the slab too. GreenGuard XPS board goes under it.
Freezer floors
Watch: Insulated panels in the yard
D.W. Ross shop floor, D.W. Ross Company. 0:20. Transcript and more videos
Send the room.
Send the room size, the temperature it holds, and the drawings if there are any. We will set the panel thickness and the skins, and quote the doors with the walls.
Questions buyers ask
What R-value does a freezer panel need?
For a cooler or freezer down to -20°F, R-32 minimum. That is about 4 in. of panel at R-8 per inch.
How thick are cold storage panels?
Standard insulated panels run from 2 to 8 in. thick, at roughly R-8 per inch. The temperature the room holds sets the thickness.
Foamed-in-place or laminated panels?
Most cooler and freezer panels we use now are foamed in place, not laminated. The foam is injected between two steel skins with tongue-and-groove edges. Compared with a laminated panel, there is very little chance of delamination, and the fire rating is better.
Will panels from two orders match?
Not always. Two runs of white can stand out beside each other, on a ceiling most of all. The minimum run is 1,000 square feet per color, so order a room's panels together.
Do you supply cold storage trim?
When we supply the panels, the formed metal trims come with them.
Who have you done cold storage work for?
Fat Head's (brewery), Great Lakes Brewing (brewery), Heritage Beverage (coors distributor) and a fishery co-op project in Craig, Alaska. Other cold-storage customers stay unnamed. Referrals on request.
Do you install cold storage panels?
Either way. Our crews install them, or we supply them material-only to the contractor on the job.
What does the room hold?
The room size, the temperature it holds, and the drawings if there are any. Attach them below.
