GreenGuard GG100-LG
100 psi XPS for the heaviest engineered loads. Kingspan names low-temperature freezer floors among its uses, alongside runways, bridge abutments and parking decks.
D.W. Ross supplies GreenGuard board for freezer and cold storage floors, and the grade is chosen with you against the slab, the load and the racking.
Specifications
As published by Kingspan. Used for: Freezer and cooler floors, High-load floors.
- Compressive strength
- 100 psi minimum
- ASTM C578
- Not stated on the current data sheet.
- Material
- Closed-cell extruded polystyrene (XPS), produced with a blowing agent blend with a GWP of less than 50.
- Size
- 2 in. thick, 2 ft wide, 8 ft long.
- R-value
- R-10 for the 2 in. board; R-5.0 per inch minimum at 75°F mean temperature, ASTM C518.
- Compressive modulus
- 3,700 psi typical, ASTM D1622.
- Flexural strength
- 100 psi minimum, ASTM C203.
- Water absorption
- 0.1% by volume maximum, ASTM C272.
- Water vapor permeance
- 0.8 perm maximum, ASTM E96 (based on 1 in. thickness).
- Dimensional stability
- 2.0% change maximum, ASTM D2126.
- Linear thermal expansion
- 3.5 x 10⁻⁵ in/in·°F, ASTM D696.
- Surface burning
- Flame spread 25 or less, smoke developed 450 or less, UL 723.
- Availability
- Confirmed by D.W. Ross in the quote for your project.
Before you specify it
- The current data sheet does not state an ASTM C578 type for this grade. Confirm the listing against the job before it goes into a specification.
- Kingspan's design note: vertical compressive strength is measured at 5% deformation or yield, and because XPS is visco-elastic, design safety factors should be used against long-term creep. Kingspan suggests 3:1 for static loads and asks to be called for dynamic loads.
- From the data sheet: the board is combustible. Protect it from high heat sources; a protective or thermal barrier may be required as specified in the building code.
Kingspan documents
These open on Kingspan’s site, so you always get the current revision. Send the data sheet and span table with your drawings and we will check the panel against the room.
Product data and images: Kingspan Insulated Panels and Kingspan Insulation. Values as published by Kingspan; the data sheet linked on each page is the current reference. Read on 2026-10-12 from Kingspan product page: GreenGuard GG100-LG and GreenGuard GG100-LG Data Sheet (Version 1.1, 12/2025).
