Shuster's · Interior doors
Stile & Rail Doors
Stile and rail interior doors in nine wood species and primed MDF: Shaker and ovolo styles, flat and raised panels, glass and true divided lite versions.
We supply the doors; the contractor doing the work installs them.
Specifications
As published by Shuster’s Building Components.
Shuster’s Stile & Rail Doors
We supply the doors; the contractor doing the work installs them.
Request a quote →- Manufacturer
- Shuster's
- Material
- Wood stile and rail
- Data read on
- 2026-10-14
- Species
- Primed MDF, Mixed Grain Pine, Vertical Grain Pine, Knotty Pine, Red Oak, Knotty Alder, Maple, White Oak and Poplar.
- Sticking
- Shaker or ovolo.
- Panels
- Flat, raised, V-grooved flat and V-grooved raised.
- Heights
- 6/8, 7/0 and 8/0 on C11, C22, C30, C35, C40, C55 and C22 raised; C11VG also 8/4; others 6/8 or 6/8 and 8/0 as printed.
- Thickness
- 1-3/4" available on C11, C22, C30 and C35; the 2025 trending flyer adds the 1501 clear glass door.
- Glass
- Clear, White Laminate, Micro-Granite, Rain, Crystal Flute and decorative.
- Configurations
- Single prehung, prehung with transom, slab with or without preps, French, bifold prehung, carton-pack bifold, bypass, Dutch, barn door.
- Bifolds
- C11, C22, C30, C35, C44, C22A, C22AVG and C44 raised.
- Availability
- Confirmed by D.W. Ross in the quote for your opening.
Styles
Names and codes as Shuster’s prints them. Ask us for the catalog page of any one.
- C111 flat panel, Shaker sticking
- C222 flat panels, Shaker sticking
- C303 equal flat panels, Shaker sticking
- C35Craftsman: 1 panel over 2 vertical, Shaker sticking
- C404 equal flat panels, Shaker sticking
- C444 flat panels, 2 by 2, Shaker sticking
- C555 equal flat panels, Shaker sticking
- C11VG1 V-grooved flat panel, Shaker sticking
- C11 / C22 ovolo1 or 2 flat panels, ovolo sticking
- C22 raised2 raised panels, ovolo sticking
- C22VG2 V-grooved raised panels
- C22A2 raised panels, arched top
- C22AVG2 V-grooved raised panels, arched top
- C44 raised4 raised panels
- C666 raised panels
- 1501Full lite, Shaker or ovolo
- C22, C30, C35, C40, C55 glassGlass versions of the flat panel styles
- 1505, 1506, 1509True divided lite, 5, 6 and 9 lite
- 1510, 1512, 1515, 1518True divided lite, 10 to 18 lite
- C22, C30, C40, C55 with clear glass1-3/8" Shaker, widths 2/0, 2/6, 3/0
More photographs
Before you order
- A matching 20 minute smooth fiberglass door is printed for many of these styles; see Stile & Rail Fire Doors.
- Shuster's marks which species it stocks for each style; we confirm the species when we quote.
Shuster’s catalogs
These open on Shuster’s own site and catalog viewer, so you always see the current edition. Find the door you want, send us the page, and we will quote it.
- Catalog2026 Stile & Rail Collection (opens the manufacturer’s site in a new tab)Flipbook
- FlyerTrending Stile & Rail Designs (opens the manufacturer’s site in a new tab)Flipbook
- FlyerTrending Interior Glass Door Designs (opens the manufacturer’s site in a new tab)Flipbook
- Drawing1 Panel Shaker 80 in. x 1.77 in. drawing (opens the manufacturer’s site in a new tab)PDF
Product data and images: Shuster's Building Components, North Huntingdon, PA. Styles and sizes as published by Shuster's; the Shuster's catalog linked on each page is the current reference. Sources, each read on the date shown:
- Shuster's product page: Stile & Rail Doors (2026-10-14)
- Shuster's 2026 Stile & Rail Collection (catalog), flipbook pages 6–43 (2026-10-14)
- Shuster's Trending Stile & Rail Designs (flyer), flipbook pages 2–4 (2026-10-14)
- Shuster's Trending Interior Glass Door Designs (flyer), flipbook pages 2–3 (2026-10-14)
- Shuster's 1 Panel Shaker 80 in. x 1.77 in. drawing (PDF) (2026-10-14)
- Shuster's catalogs page (2026-10-14)
What we need to quote Stile & Rail Doors.
Interior or exterior, rough opening, swing and the style you want, or a photo. We confirm the size, glass and finish and quote the door.
