DynamicRoll CB 125 TM Cleanroom High-Speed Door
A high-speed cleanroom door with the motor inside the drive drum, a fully enclosed compact frame and a magnetic sealing option, for separating cleanroom zones.
D.W. Ross supplies Jamison cooler, freezer and clean-room doors, sized to the opening before anything is ordered. It can install the door it supplies or deliver it material-only for your contractor.
Specifications
As published by Jamison for the DynamicRoll® CB 125 TM Cleanroom High Speed Door.
Jamison DynamicRoll CB 125 TM Cleanroom High-Speed Door
Send the opening size and the temperature on each side. We confirm the door, its rating and its options.
Request a quote →- Manufacturer
- Jamison Door Company
- Catalog group
- Clean-room doors
- Data read on
- 2026-10-14
- Door type
- High-speed roll-up
- Application
- Clean room, Pharmaceutical
- Jamison line
- DynamicRoll (DynamicRoll high-speed doors)
- Maximum size
- W 13' x H 13'
- Opening speed
- Up to 120 in/sec
- Cycle test
- 1,000,000
- Air permeability
- Standard Class 2 Optional Class 5 - Patented magnetic system
- Sliding system
- Patented sliding system with high density polyzene self-lubricating encapsulated curtain edge
- Safety devices
- Standard: Photocells, unroll sensor, and Wi-Fi safety edge; Optional: Multi ray light curtain barrier
- Availability
- Confirmed by D.W. Ross in the quote for your opening.
How Jamison builds it
- Brushless tubular motor inside the drive drum, no side-mounted motor.
- Patented magnetic sealing system (air permeability Class 5 option).
- Jamison states Fraunhofer tested it for ISO 5 and GMP Class C cleanrooms.
- RAL-coated or stainless steel finishes; sloped covers; bolt-free surfaces that mount to cleanroom panels.
More photographs
Before you specify it
- Curtain fabric options are confirmed against the data sheet in the quote.
Jamison literature
We send Jamison’s current sheet with the quote, so you are never working from an old revision. Send it back with your drawings and we will check the door against the opening.
- BrochureDynamicRoll CB 125 TM high-speed cleanroom door brochurePDF
Product data and images: Jamison Door Company. Values as published by Jamison on its product pages; the current Jamison data sheet is the reference, and D.W. Ross supplies it with the quote. Read on 2026-10-14 from Jamison’s public product page for the DynamicRoll® CB 125 TM Cleanroom High Speed Door.
Tell us about the opening.
The opening size, the temperature on each side, the traffic and how the room is cleaned. We confirm the door, its rating and its options, and quote it.
